| Brand Name: | Ebuddy |
| Model Number: | BNVD-8 |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | 3-5days for samples |
| Payment Terms: | L/C, T/T, Western Union,Paypal |
4-Pin ANVS Lemo Female Connector PHG.0B.304 For Night Version Systems
1) Apply to the night version systems AVNS connectors
2) 4pin female Lemo connector PHG.0B.304
3) Color: Standard Black and Silver color for your option, other customized color also available
4) Assembly: We also can do cable assembly with overmold
5) Warranty time: We will supply 12 months warranty time for all our connectors and cables.
This 4pin AVNS female connector is using push pull self latching structure, make it easy for mating and unmating. Widely use for the Night version systems, we specially plating black color to match the environment of Night vision devices.
| Shell Style/Model | PH*: Free receptacle, cable collet and nut for fitting a bend relief |
| Keying | 1 key (alpha=0, plug: male contacts, receptacle: female contacts) |
| Housing Material | Brass (black chrome) shell and collet nut, nickel plated [SAE AMS QQ N 290] brass latch sleeve and mid pieces |
| Rated Current | 7A |
| Contact Dia | 0.7 mm (0.028in) |
| R (max) | 6.1 mOhm |
| Contact Type | Solder |
| Vtest | 700-1000V |
| Endurance (Shell) | 5000 |
1. Q: Are you a factory or trade company?
A: We are manufacturer of connectors and cables with 10 years experience.
2.Q: Do you provide samples? Is it free?
A: We can provide a small number of free samples, but you need to pay the freight.
3.Q: What can you buy from us?
A: Push-pull connectors, cable assembly, bayonet connectors, military connectors,
custom connectors.
4. Q: What about the leading time?
A: If there's stock, we ship th e goods within 3-5 working days after the deposit is
confirmed. Or else, it depends on the quantity you need.
5. Q: What payment methods you support?
A: We accept T/T, Paypal, Western Union
